Features:

* Suitable for cutting aluminum curtain wall profiles, window door profiles and PVC profiles

*Feeding system adopts imported linear, high precision and good stability.

*The right head movement adopts high guiding ball screw movement, with high transmission accuracy, accurate positioning and stable work.

*The two saw heads can automatically convert the angle to achieve 45° flip inside and outside and 90° profile angle cutting.

*Hard alloy saw blade with high processing precision and durability.

*Imported linear bearing with stable working precision.

*High precision spindle, saw blade rotation is stable.

*Pneumatic-hydraulic damping cylinder realizes even speed regulation for feeding and smooth movement.

*Automatic opening and closing guard makes the work safe and convenient.

Parameters:

Control form: digital display, electric control

After-sales service: one year warranty, maintenance for life

Motor power: 4.4KW

Maximum sawing diameter: 160mm

Cutting seam width: 4mm

Weight: 1400kg

Overall dimension: 5500mm×1750mm×1990mm

Layout form: horizontal

Object material: aluminum profile
